DESIGNED AND MADE IN CALIFORNIA
Calx
pendant
- Calx 36
- Dimensions: 25" x 25", 22.75"
- Materials: wood, metal, polymer
- Product weight: 18 lb
- Light source: 4x GU-24 base socket
- Lamping: 4x GU-24 base, 18 W max each
- Bulbs not included
- Input voltage: 300 V AC max
- White (CM-060) 8" round canopy included
- Canopy dimensions: 8"ø, 1.25"
- See website for more canopy information
- 96" drop length, field adjustable
- Suitable for a sloped ceiling
- Wood grain will vary
- Specifications subject to change
- Calx 19
- Dimensions: 13" x 13", 12.75"
- Materials: wood, metal, polymer
- Product weight: 7 lb
- Suitable for a sloped ceiling
- Integrated LED Specifications
- Light output: 1647 Lumens (source), based on 2700K
- Light color*: 2700 K or 3500 K
- Color accuracy: 90+ CRI
- Power usage: 19 W
- Dimmable (see driver below)
- White (CM-060) extended-profile round canopy with white braided cord and steel cable included
- Canopy dimensions: 5"ø, 2"
- Canopy required to house LED driver (3.3" x 1.6" x 1.0")
- See website for more canopy information
- 72" drop length, field adjustable
- Medium Base Specifications
- Lamping: 1x E26 base, type A lamp, 60 W max
- Bulb not included
- Input voltage: 250 V AC max
- White (CM-060) low-profile round canopy with white SPT cord and steel cable included
- Canopy dimensions: 5"ø, 0.3"
- 72" drop length, field adjustable
- Wood grain will vary
- Specifications subject to change
- *Available in 3000K, 4000K and other color temperatures upon request
- Calx 10
- Dimensions: 6.75" x 6.75", 6.4"
- Materials: wood, metal, polymer
- Product weight: 2 lb
- Light source: integrated LED
- Light output: 345 Lumens (source)
- Light color*: 2700 K or 3500 K
- Color accuracy: 90+ CRI
- Power usage: 3.2 W
- Dimmable (see driver below)
- Driver location: must be housed in J-box
- Driver dimensions: 2" x 1.3" x 1", included
- White (CM-060) low-profile round canopy with white braided cord included
- Canopy dimensions: 5"ø, 0.3"
- See website for more canopy information
- 72" drop length, field adjustable
- Suitable for a sloped ceiling
- Wood grain will vary
- Specifications subject to change
- *Available in 3000K, 4000K and other color temperatures upon request
- Calx sconce also available. Click here.
California Prop 65 Warning
- CALX 10 TEARSHEET
- CALX 10 INSTRUCTIONS
- CALX 19 TEARSHEET
- CALX 19 INSTRUCTIONS E26 SOCKET
- CALX 19 INSTRUCTIONS
- CALX 36 TEARSHEET
- CALX 36 PHOTOMETRIC DATA
- CALX 36 INSTRUCTIONS
- GENERAL PRODUCT CARE SHEET
The Calx is an example of modern design where the methods and the materials themselves are integral to its very conception, aligning form and function, which creates a synergy that is evident. The fixture ultimately forms a square aperture but enjoys a beautifully simple faceted structure.
— Nick Sheridan, Designer
Calx
MATERIAL AND FINISH OPTIONS
Calx part # 06-200---
- Calx 10
- Calx 19
- Calx 36
- brushed aluminum (CM-012)
- brushed rose gold (CM-046)
- brushed brass (CM-047)
- walnut (CM-055)
- dark stained walnut (CM-056)
- white washed oak (CM-095)
- 2700 K LED
- 3500 K LED
- Calx 36
- Calx 10 120 V AC input voltage TRIAC, ELV, or 0-10V dimmable
- Calx 19 AC Input Voltage Range: 120-277 V, 0-10 V dimming at 120-277 V AC, TRIAC and ELV dimming at 120 V AC only
- Calx 36
- Calx 10: White (CM-060) low-profile round canopy with white braided cord
- Calx 19 Integrated LED: White (CM-060) extended-profile round canopy with white braided cord and steel cable
- Calx 19 Medium Base: White (CM-060) low-profile round canopy with white SPT cord and steel cable included
- Calx 36: White (CM-060) 8" round canopy
